The DA1110-RM Multispan PoE injector is ideal for indoor environments where up to four devices require up to 30W each of PoE power. You can connect devices to be powered with or without a data connection and any spare ports of the 5-port network switch can be used for other network devices.
All SecurePoE Multispan models have an integrated 5-port Gigabit network switch. This allows all the PoE through-port channels to be bridged, allowing data connections to multiple ports with a single or dual Ethernet connection from the SecurePoE unit to existing network infrastructure.
Gigabit and 10/100Mbs versions are available.
All Multispan models include 200mm Ethernet patch cables between the PoE injector ports and the integrated 5-port network switch.
These larger units maintain 10Ah of PoE power to devices during long power interruptions and major faults. The 10Ah stand-by battery pack will maintain a 20W load for approximately 20 hours or small 5W devices for up to 100 hours after a power failure. The main unit itself requires just 1U of rack space. The remote battery pack, connected via a tamper-looped lead, can be installed in or near the rack cabinet as needed.
Multispan and MultispanUPS products include a 5-port network switch. Available in an indoor mild steel wall mount enclosure, exterior IP66 weather-resistant enclosure ideal for harsh environments, or simply as a 1U rack-mount product.
These switched Multispan models are ideal for installations where there is limited access to, or availability of, Ethernet ports on the network. Only a single Ethernet data cable is required to send and receive data from up to four devices, whether or not they require Power over Ethernet.
Network switch pre-installed in Multispan SecurePoE units
No software to configure
Network switch and PoE power are both battery-backed in 1.2Ah, 7Ah and 10Ah MultispanUPS models
Maintain data network during accidental or deliberate power failures or faults
Gigabit Ethernet delivers high-speed connectivity to enhance network performance
200mm Ethernet patch cables to SecurePoE ports included
Easily keep security infrastructure independent of existing networks
Only one Ethernet cable is required to bridge to existing network infrastructure
Ability to extend the range of Power over Ethernet and network, up to 200m between network and PoE devices
Estimated stand-by times
Designed for reliable battery back-up of PoE devices, our SecurePoEâ„¢ range includes battery-maintained MidspanUPS and MultispanUPS models that provide continuous power to PoE ports when mains power is not available. The MultispanUPS models maintain power to both the SecurePoE unit and the included Cisco network switch.
Power back-up is provided by our replaceable, customized battery packs, which use high reliability Yuasa batteries. Different capacities are available to cater for different stand-by time requirements and we offer guaranteed replacement battery pack availability.
Whether powering CCTV cameras, video intercoms, locks or other device types, Power over Ethernet battery stand-by is available off-the-shelf.
